Product Overview
When a PACSystems RX3i line goes down, every hour of downtime burns production. The GE IC695MDL753 answers that problem with 32 sourcing transistor outputs in a single slot, so you drive more field devices without expanding the rack. This module carries the GE Fanuc / GE Intelligent Platforms lineage, and Emerson now owns the platform.
Technical Specifications
Each output switches 24 V DC (±15%) at 0.5 A per channel. That current level suits indicator lamps, small solenoids, and pilot relays without external interposing hardware. The sourcing (PNP) design delivers positive voltage to the load, which matches many sensors and input cards wired to a common ground.
The module draws 5 V DC from the backplane bus, keeping field wiring simple. Its IP20 rating means it belongs inside a clean cabinet, protected from dust and moisture. Ambient operating range runs 0 to +60°C, and storage survives -40 to +85°C. Relative humidity of 5 to 95% non-condensing covers most plant environments. Dimensions measure roughly 178 × 127 × 51 mm, a standard RX3i footprint.
Where It Fits
Oil and gas facilities often need dense discrete output banks for valve piloting, pump status, and alarm annunciation. The IC695MDL753 covers those jobs in one slot. Packaging and material-handling lines also benefit: 32 points reduce spare-part count and cabinet space. Water treatment plants use sourcing outputs for motor starters and chemical dosing signals. In each case, the 0.5 A per-channel rating keeps small loads direct and simple.
Installation and Setup
Mount the module in an RX3i rack and confirm the backplane supplies 5 V DC. Keep field wiring separated from high-voltage runs to reduce noise. Verify that each load stays within the 24 V DC ±15% window and 0.5 A limit. Because the outputs source current, wire the load return to the common ground. Follow the manufacturer’s safety manual for cabinet grounding and segregation. If you are replacing an older module, check the rack slot and terminal layout before power-up.
Reliability and Maintenance
Inspect terminal connections periodically and confirm cabinet cooling holds ambient below +60°C. Dust buildup raises internal temperature, so clean the enclosure on a routine schedule. Humidity above 95% can cause condensation, so verify the cabinet environment stays within the stated range. Keep a spare module on the shelf: fast dispatch, worldwide means a replacement arrives before the next shift. That practical approach protects throughput and avoids long production gaps.
Selection and Compatibility
The IC695MDL753 belongs to the PACSystems RX3i series, so it integrates with existing RX3i racks and power supplies. Before ordering, confirm your rack has an open slot and that your field devices accept sourcing outputs. Buyers should also verify the load voltage and current for every channel. Oil AutoTech offers hands-on technical selection help to match this module to your application. Please verify current lifecycle status and availability with Oil AutoTech before ordering, since official Emerson production status is unverified and units currently move through aftermarket channels.
Key Takeaways
- 32 sourcing transistor outputs in one RX3i slot
- 24 V DC (±15%) load voltage, 0.5 A per channel
- 5 V DC backplane draw, IP20 protection
- Operating range 0 to +60°C, storage -40 to +85°C
- Available in aftermarket channels as of 2026-09
Contact Oil AutoTech today for pricing and availability.
