What Makes the 170MCI10001 the Right Cable for Your Quantum System?
How often does a stalled data link on the plant floor trace back to a single cable? In Interbus networks running Modicon Quantum hardware, the answer is more often than most maintenance teams expect. The Schneider Electric 170MCI10001 is a 1 m communication cable built specifically for that job: linking devices inside the Modicon Quantum series over the Interbus protocol.
This is not a generic patch lead. It is a purpose-built spare for an installed automation platform, and it is ready-to-ship from Oil AutoTech when a line is down and every hour counts.
Key Parameters at a Glance
| Specification | Value |
|---|---|
| Manufacturer | Schneider Electric |
| Product type | Cable |
| Product line | Modicon Quantum |
| Part number | 170MCI10001 |
| Protocol | Interbus |
| Length | 1 m |
| Color | Black |
| Weight | 0.19 lbs (0.09 kg) |
| EAN | 3595860027139 |
Why the 1 m Length and Interbus Protocol Matter
Cable length is a practical constraint, not a footnote. At 1 m, the 170MCI10001 suits cabinet-internal runs and short device-to-device links where excess cable creates strain and clutter. The Interbus protocol support means the cable is matched to the network it serves, so you are not adapting a general-purpose lead to a fieldbus task.
Environmental Envelope
The cable operates from 0 to 40 degrees Celsius and stores from 0 to 50 degrees Celsius. It tolerates up to 80% RH without condensation in both states, and it is rated for altitudes up to 1000 meters above sea level without derating. Schneider Electric specifies it for indoor environments free of corrosive chemicals.
Where the 170MCI10001 Fits on the Plant Floor
Cabinet-internal Interbus links. Control cabinets on oil and gas skids often pack Quantum I/O and communication modules into tight spaces. A 1 m cable keeps routing clean and reduces the chance of snagging during service.
Replacement during planned outages. When a turnarounds window is fixed, having the correct Interbus cable on the shelf avoids a scramble. Fast dispatch, worldwide, keeps that window intact.
Spare-parts stocking. Maintenance planners who hold one or two of these cables avoid the classic scenario: a healthy controller, a healthy module, and a dead link that stops production.
Installation and Handling Notes
Treat the 170MCI10001 as a precision interconnect. Route it away from sharp panel edges and heavy-duty power conductors, respect the minimum bend radius, and secure it so vibration cannot work the connectors loose. Keep the run inside the specified temperature and humidity envelope, and confirm the cabinet stays free of corrosive vapors. Before commissioning, verify pinout and connector orientation against your Quantum documentation. If you need help matching this cable to your exact configuration, Oil AutoTech offers hands-on technical selection support.
Reliability and Maintenance
Inspect the cable during routine cabinet checks. Look for abrasion, kinked sections, and connector strain. Because the operating window tops out at 40 degrees Celsius, watch panel temperatures in enclosures with poor airflow; sustained heat shortens cable life. In humid plants, confirm that the 80% RH limit is not exceeded and that no condensation forms on the cable or connectors. Replacing a suspect cable before it fails is almost always cheaper than an unplanned stoppage.
Compatibility and Integration
The 170MCI10001 belongs to the Modicon Quantum line and carries Interbus traffic. Integration Note: wiring into an Interbus network may require an external gateway or connection module depending on your architecture. Confirm the required cables, connectors, and gateways with your supplier before ordering.
Selection Checklist
Before you buy, confirm the part number 170MCI10001, the Interbus protocol requirement, and the 1 m length against your installation. Check that your environment stays within 0 to 40 degrees Celsius, 80% RH without condensation, and 1000 meters altitude. If any point is unclear, contact Oil AutoTech today for pricing and availability.
Please verify current lifecycle status and availability with Oil AutoTech before ordering.
