170XTS00501 Busbar: The Backbone of Modicon Momentum I/O
Downtime in oil, gas, and industrial automation often traces back to a small connection component. The Schneider Electric 170XTS00501 is a busbar built for the Modicon Momentum automation platform. It provides a common connection for field devices and serves as a protective distribution connector for discrete and analog I/O bases.
This is not a complex controller — it is the practical, reliable link that keeps your I/O bases organized and your field wiring clean. When a busbar fails or goes missing, your entire I/O slice can stall. That is why having a ready-to-ship spare matters.
Technical Specifications
| Specification | Value |
|---|---|
| Manufacturer | Schneider Electric |
| Product Line | Modicon Momentum |
| Part Number | 170XTS00501 |
| Accessory Type | Busbar |
| Designation | Busbar, 2 rows |
| Connections | Screw type terminals |
| Number of Horizontal Rows | 2 |
| Material | Bus Bar |
| Operating Temperature | 0 to 60 degrees Celsius |
| Operating Humidity | Up to 80% (non-condensing) |
| Storage Humidity | Up to 80% (non-condensing) |
| Max Operating Altitude | 1000 meters above sea level |
| Weight | 0.15 lbs |
| Destination | Discrete I/O base, Analog I/O base |
Why the 170XTS00501 Matters in Your Panel
Two Rows, Clean Distribution
The 170XTS00501 manages two horizontal rows. This layout gives you a structured way to route common connections across Momentum I/O bases. Instead of daisy-chaining wires by hand, the busbar provides a fixed, repeatable distribution point.
Screw Terminals for Field Reliability
Screw type terminals remain the standard in harsh environments because they tolerate vibration and temperature swings better than push-in alternatives. For oil and gas installations where panels face constant vibration, this connection style is a practical choice.
Built for Real-World Conditions
With an operating range of 0 to 60 degrees Celsius and 80% non-condensing humidity, this busbar handles the conditions found in most control rooms and sheltered cabinets. The 1000-meter altitude limit covers the vast majority of land-based installations.
Where the 170XTS00501 Fits
Discrete I/O bases — The busbar distributes common connections across digital input and output modules, keeping wiring organized when you have multiple I/O slices in one Momentum assembly.
Analog I/O bases — Analog signals are sensitive to noise and poor connections. A solid busbar helps maintain a stable reference and reduces the chance of intermittent faults.
Retrofit and replacement — If you are maintaining an existing Momentum system, the 170XTS00501 is the correct accessory for discrete and analog I/O bases. It is a direct-fit component, not a universal substitute.
Installation and Compatibility Notes
The 170XTS00501 is designed specifically for the Modicon Momentum platform. It mounts as part of the I/O base assembly and uses screw type terminals for field connections. Before installation, verify that your I/O base accepts this busbar configuration.
Because this is a connection accessory, proper torque on screw terminals matters. Follow your panel wiring standards and the manufacturer’s documentation. Do not overtighten, as this can damage the terminal block.
If you are integrating into a larger control system, confirm that your Momentum assembly uses the same busbar style. Mixing accessory revisions can lead to poor contact and intermittent faults.
Maintenance and Long-Term Reliability
Busbars are passive components, but they still benefit from periodic inspection. Check for loose screws, discoloration from heat, and signs of corrosion. In oil and gas environments, contaminants can build up on exposed metal surfaces over time.
A simple annual inspection during scheduled downtime can catch issues before they cause a stoppage. If you notice pitting or heavy oxidation, replace the busbar rather than trying to clean it. The low weight (0.15 lbs) and simple design make replacement straightforward.
Selection Checklist
Before ordering the 170XTS00501, confirm:
- Your I/O base is part of the Modicon Momentum platform.
- You need a 2-row busbar with screw type terminals.
- Your panel operates within 0 to 60 degrees Celsius and 80% non-condensing humidity.
- The installation altitude is at or below 1000 meters.
Please verify current lifecycle status and availability with Oil AutoTech before ordering.
