What Makes the 170BAI03600 the Right Analog Input Module for Your Panel?
How do you capture eight live process signals without adding eight separate devices to an already crowded control cabinet? The Schneider Electric 170BAI03600 answers that question directly. Part of the Modicon Momentum product line, this analog input module packs eight separate channels into one compact unit, so a single slot handles multiple measurements at once. For oil, gas and industrial automation teams, that means fewer components, simpler panels and faster commissioning.
Key Parameters That Matter on the Plant Floor
Eight Channels, One Module
Eight independent channels let the 170BAI03600 process multiple signals simultaneously. Instead of stacking single-channel cards, engineers gain density and save enclosure space.
24 V DC at 1 A
The module runs on 24 V DC and handles a current of 1 A. That matches the power specification common in existing automation systems, so integration into an established cabinet is straightforward.
Built for Real Industrial Conditions
The 170BAI03600 operates from 0 to 60 degrees Celsius and tolerates up to 80% relative humidity, non-condensing, both in operation and in storage. It is rated for altitudes up to 1000 meters above sea level. At just 0.75 lbs (0.34 kg), it adds almost no weight to a DIN rail assembly.
Where the 170BAI03600 Fits
Oil and Gas Skids
On a metering or compressor skid, eight channels can gather pressure, flow and temperature signals in one place. The 24 V DC supply matches typical skid power, and the 0-60 degrees Celsius range suits sheltered field cabinets.
Process and Utility Panels
Water treatment, pump stations and packaged process units often need several analog points close together. One 170BAI03600 replaces multiple single-channel modules, which cuts wiring time and panel cost.
Upgrading Legacy Momentum Systems
If you maintain a Modicon Momentum installation, this module is a practical drop-in for expanding analog capacity without redesigning the whole rack.
Installation and Setup Notes
Mount the module on a standard DIN rail inside a dry, non-condensing environment. Verify that the 24 V DC supply can deliver the 1 A the module requires, and keep ambient temperature within the 0-60 degrees Celsius window. Confirm channel assignments and signal wiring against your system documentation before power-up. If you are unsure which module suits your rack, our team offers hands-on technical selection help.
Keeping the Module Reliable
Inspect terminals and connections periodically for looseness or corrosion. Keep cabinet filters clean so humidity and heat stay within the rated 80% RH and 60 degrees Celsius limits. Avoid mounting above 1000 meters without checking derating guidance. These simple habits protect uptime and protect your spares budget.
Choosing the Right Module
Before ordering, confirm your channel count, supply voltage and cabinet conditions. The 170BAI03600 covers eight channels at 24 V DC and 1 A, with a 0-60 degrees Celsius operating window. Please verify current lifecycle status and availability with Oil AutoTech before ordering. We keep fast-dispatch spares for oil, gas and industrial automation, with quick worldwide delivery. Contact Oil AutoTech today for pricing and availability.
