What Slows Down Your Quantum Control Cabinet?
Is a missing operator interface holding up your Modicon Quantum line? The Schneider Electric 140NWM10000C is a dedicated operator panel built for the Modicon Quantum series. It gives operators a clear LED display for interacting with industrial control systems, and it arrives ready-to-ship from Oil AutoTech.
Product Overview
The 140NWM10000C belongs to Schneider Electric’s Modicon Quantum product line. It presents system information through an LED display, so users can read status and interact with the control system directly at the cabinet. Two connection ports support MT-RJ and RJ-45 connectors, which simplifies linking the panel into existing Quantum installations.
Key Parameters
| Specification | Value |
|---|---|
| Product Type | Operator Panel |
| Product Line | Modicon Quantum |
| Display Type | LED |
| Connection Ports | 2 |
| Connector Type | MT-RJ, RJ-45 |
| Standards Compliance | CE |
| Protection Class | IP20 |
| Enclosure Rating | NEMA 1 |
| Max. Ambient Temperature | 40 degrees Celsius |
| Min. Ambient Temperature | 0 degrees Celsius |
| Max. Operating Humidity | 80% RH, non-condensing |
| Max. Storage Humidity | 80% RH, non-condensing |
| Max. Operating Altitude | 1000m above sea level |
What the Ratings Mean in Practice
The IP20 protection class shields internal components from dust and other environmental factors, while the NEMA 1 enclosure rating suits indoor settings. The panel performs efficiently where ambient temperature ranges from 0 to 40 degrees Celsius, and it tolerates operating and storage humidity levels of up to 80% RH. Installations at altitudes up to 1000 meters above sea level are equally supported.
Where This Panel Fits
Oil, gas, and industrial automation sites often run Quantum racks in control rooms where operators need fast, local status feedback. The 140NWM10000C fits that role: an indoor panel that keeps personnel informed without opening the cabinet. Because the unit carries CE compliance, it slots into European-style control builds without extra qualification steps.
Integration Note
Wiring the 140NWM10000C into an existing network may require an external gateway or connection module. Confirm the correct cables and gateways with your supplier before commissioning.
Selection and Sourcing Advice
Before ordering, verify your rack slot, connector type (MT-RJ or RJ-45), and the ambient conditions at the mounting location. The 140NWM10000C is designed for indoor use only, so outdoor or washdown areas need a different enclosure strategy. Oil AutoTech offers hands-on technical selection help, so you can match the panel to your Quantum configuration without guesswork.
Please verify current lifecycle status and availability with Oil AutoTech before ordering.
Reliability and Maintenance
Inspect the panel periodically for dust buildup on the LED display and around the ports. Keep cabinet doors closed to maintain the NEMA 1 rating, and monitor room temperature to stay within the 0 to 40 degrees Celsius window. Follow the manufacturer’s safety manual for all service work.
Frequently Asked Questions
What is the 140NWM10000C?
It is a Schneider Electric operator panel in the Modicon Quantum series, featuring an LED display and two connection ports.
Which connectors does it use?
The panel supports MT-RJ and RJ-45 connector types.
What environmental conditions does it handle?
It operates from 0 to 40 degrees Celsius, up to 80% RH non-condensing, and at altitudes up to 1000 meters above sea level.
Is it suitable for outdoor installation?
No. The NEMA 1 enclosure rating is intended for indoor settings.
Can I get technical help choosing the right panel?
Yes. Contact Oil AutoTech today for pricing and availability, and our team will help you confirm the right fit.
