140CPS21400C | Schneider Electric Modicon Quantum Power Supply Module

The 140CPS21400C power supply module from Schneider Electric's Modicon Quantum series operates efficiently with an input voltage between 20 and 30 volts DC. It can handle an input current of 3800 mA and provides a stable output voltage of 5.1 volts DC for various applications.

Technical specifications for 140CPS21400C
Manufacturer Schneider Electric
Product Line Modicon Quantum
Part Number 140CPS21400C
EAN 3595861136007
Name Power Supply Module
Input Voltage 24 V (20...30 V) DC
Input Current 3800 mA
Inrush Current 14 A at 20 V; 25 A at 24 V
Max. Input Power Interruption 100 ms; 1 ms at 20 V
Associated Fuse Rating 5 A
Output Voltage 5.1 V DC
Power Supply Output Current 8 A summable
Resistance to Electromagnetic Fields 10 V/m at 80…2000 MHz
Relative Humidity 95 % without condensation
Operating Altitude <= 5000 m Ambient Air Temperature for Operation 0…60 °C Resistance to Electrostatic Discharge 4 kV Description Schneider Electric's 140CPS21400C is a power supply module designed for reliable operation in various environments. It accepts an input voltage of 24 V DC, with a permitted range from 20 V to 30 V and consumes an input current of 3800 mA. The module exhibits a notable inrush current of 14 A when the input voltage is at 20 V and 25 A at 24 V, allowing for robust initial operation when powered on. Output stability is ensured, with the module supplying 5.1 V DC at a maximum output current capacity of 8 A, making it suitable for demanding applications. The design incorporates an associated fuse rating of 5 A and can handle an input power interruption of 100 milliseconds, or as brief as 1 millisecond at 20 V. Resistance to electromagnetic fields is adequate, rated at 10 V/m across frequencies from 80 to 2000 MHz, ensuring compatibility in environments with potential interference. The 140CPS21400C can function under ambient conditions with temperatures ranging from 0 to 60 °C and can be installed at altitudes of up to 5000 meters. Additionally, it withstands relative humidity levels of up to 95% without condensation. Electrostatic discharge resistance is rated at 4 kV, contributing to its reliability in industrial settings. At a net weight of 0.65 kg and dimensions of 16.3 cm high, 4.5 cm wide, and 31.2 cm long, this module is designed for ease of integration into control systems. This makes it an essential component for power management in Schneider Electric's Modicon Quantum installations. Range of Product Modicon Quantum automation platform Product or Component Type Power supply module Power supply type Summable Complementary Input voltage 24 V 20...30 V) DC Input current 3800 mA Inrush current 14 A 20 V 25 A 24 V Maximum input power interruption 100 ms 1 ms 20 V Associated fuse rating 5 A, slow-blow Output voltage 5.1 V DC Power supply output current 8 A summable Output overvoltage protection Internal Output overload protection Internal Power dissipation 6 + (1.8 x Iout) where Iout is in A Alarm output 1 NC 6 A 220 V power supply fault Local signalling 1 LED (green) for power (PWR OK) Marking CE Module format Standard Net Weight 1.43 lb(US) (0.65 kg) Environment Protective treatment Conformal coating Humiseal 1A33 Standards CSA C22.2 No 142 UL 508 Product Certifications cUL FM Class 1 Division 2 Resistance to electrostatic discharge 4 kV contact IEC 801-2 8 kV on air IEC 801-2 Resistance to electromagnetic fields 9.1 V/m (10 V/m) 80…2000 MHz IEC 801-3 Ambient Air Temperature for Operation 32…140 °F (0…60 °C) Ambient Air Temperature for Storage -40…185 °F (-40…85 °C) Relative Humidity 95 % without condensation Operating altitude <= 16404.2 ft (5000 m) Ordering and shipping details Category US1PC2118155 Discount Schedule PC21 GTIN 3595861136007 Returnability No Packing Units Unit Type of Package 1 PCE Nbr. of units in pkg. 1 Package 1 Height 6.4 in (16.3 cm) Package 1 Width 1.8 in (4.5 cm) Package 1 Length 12.3 in (31.2 cm) Package weight(Lbs) 29.1 oz (825.0 g)
